4060 Structural Aluminum Framing Profile 1500mm Black Anodized for Fiber Laser Cutting Machine Stand

Product Introduction Of 4060 Structural Aluminum Framing Profile 1500mm Black Anodized:

4060 Structural Aluminum Framing Profile is a premium 40mm×60mm heavy-duty T-slot aluminum extrusion with a standard factory length of 1500mm, finished with high-quality black anodized treatment. Made of industrial grade 6063-T5 aluminum alloy, this profile features rigid integrated extrusion structure, excellent straightness and strong load-bearing performance. It is professionally customized for building fiber laser cutting machine stand, base frame and equipment support structure. Adopting universal 4-side T-slot modular design, it needs no welding, allows fast assembly, disassembly and flexible layout adjustment. The black anodized surface is oil-proof, scratch-resistant and corrosion-resistant, perfectly adapting to workshop dusty, oily and long-term working environment of laser cutting equipment.

Product Specification Table Of 4060 Structural Aluminum Framing Profile 1500mm Black Anodized:

Specification Item	Parameter Details
Product Model	4060 T-Slot Structural Aluminum Framing Profile
Section Size	40mm × 60mm
Standard Length	1500mm
Aluminum Alloy Grade	6063-T5 Industrial Temper
Wall Thickness	2.0mm Heavy Duty
Standard T-Slot Width	8mm (Fit M8 Standard Hardware)
Weight Per Meter	2.95kg/m
Surface Finish	Matte Black Hard Anodized
Structural Design	Four Sides Open T-Slot Modular Frame
Straightness Tolerance	≤0.3mm per meter
Custom Processing	Support Cutting, Drilling, Tapping, Chamfering
Load Type	Medium to Heavy Industrial Static Load

Application Scenarios Of 4060 Structural Aluminum Framing Profile 1500mm Black Anodized:

1. Fiber laser cutting machine stand, base frame and support leg construction
2. Laser engraving and marking machine overall structural framing
3. CNC router and milling machine equipment base and protective frame
4. Industrial automation equipment cabinet and mechanical support frame
5. Workshop heavy-duty workbench and testing jig framing
6. Production line equipment bracket and isolation safety guard
7. Laboratory precision instrument mounting frame and equipment platform
8. DIY industrial machine frame and factory customized equipment structure

Product Processing & Surface Treatment Of 4060 Structural Aluminum Framing Profile 1500mm Black Anodized:

Product Processing Methods

1. Precision fixed-length cutting at 1500mm with strict size tolerance control
2. Full edge deburring and 45° chamfering to remove sharp burrs for safe installation
3. Custom service of drilling, tapping and slot milling for laser machine assembly holes
4. 90°/45° angle cutting for corner connection of integral machine stand
5. Surface cleaning and residue removal to ensure smooth T-slot sliding of accessories

Surface Treatment Methods

1. Matte Black Anodized: Thickened oxide layer, anti-corrosion, anti-oil, anti-scratch, industrial high-grade appearance
2. Silver Clear Anodized: Natural metal texture, wear-resistant, suitable for indoor general equipment frame
3. Sandblasted Anodized: Uniform matte surface, stronger dust and oil resistance for workshop environment
4. Electrophoretic Coating: High weather resistance, suitable for semi-outdoor laser equipment placement

Product Advantages Of 4060 Structural Aluminum Framing Profile 1500mm Black Anodized:

1. High-strength 6063-T5 aluminum alloy with 2.0mm thick wall, stable structure, not easy to deform for long-term laser machine use
2. Premium black anodized finish, effectively resistant to workshop dust, oil stain and oxidation, long service life
3. Standard 8mm T-slot design, fully compatible with 40 series M8 bolts, nuts, angle brackets and all matching accessories
4. Modular assembly design, no welding required, easy to splice, adjust and expand the laser machine frame structure
5. High-precision extrusion molding, excellent straightness, ensuring installation accuracy and operation stability of laser equipment
6. 4060 widened and thickened section design, stronger load-bearing capacity than conventional profiles, ideal for heavy machine stands
7. Lightweight than steel frame, easy to transport and install, reducing overall equipment self-weight
8. Multiple processing and surface options available, meeting personalized customization needs of different laser equipment models

FAQs Of 4060 Structural Aluminum Framing Profile 1500mm Black Anodized:

Q1: What material is this 4060 aluminum profile made of?

It is crafted from industrial standard 6063-T5 aluminum alloy, which features high hardness, good toughness and anti-deformation performance, specially suitable for fiber laser cutting machine stand construction.

Q2: Is this 1500mm profile perfect for fiber laser cutting machine stand?

Yes. The 4060 heavy-duty section and rigid structure are professionally designed for laser machine base and support frame, providing stable bearing and vibration reduction during equipment operation.

Q3: Can I cut the 1500mm profile into custom shorter lengths?

Certainly. The aluminum profile can be easily cut with an aluminum saw, and we also provide free custom cutting, deburring and chamfering services.

Q4: What hardware accessories match the T-slot of this profile?

It matches universal M8 T-bolts, slot nuts, L-type angle brackets, connection plates and end caps, all common 40 series aluminum extrusion accessories on the market.

Q5: Does the black anodized surface resist workshop oil and dust?

Absolutely. The hard black anodized layer has good oil-proof, dust-proof and scratch-resistant properties, keeping stable appearance and performance in long-term workshop working conditions.

Q6: What is the load-bearing capacity of this 4060 structural profile?

With 2.0mm wall thickness and 40×60mm cross section, it supports medium and heavy static load, fully meeting the weight bearing and stability requirements of conventional fiber laser cutting machines.

Q7: Can this profile be used to build CNC and laser engraver frames?

Yes, it is widely applicable for laser engraving machines, CNC routers, automation equipment bases and various industrial mechanical framing projects.

Q8: Are the profile edges sharp after processing?

No. All profiles undergo full deburring and chamfering treatment, with smooth edges and no burrs, ensuring safe manual assembly and installation.

---
